Description

Brief Introduction

Concrete mixing truck consists of truck chassis and concrete mixing delivery device, mixing tank keeping rolling during the transportation process. It is special purpose vehicle that combines the functions of concrete mixing and delivery.

Concrete mixer truck features

1. The whole truck is convenient and stable with strong intensity.

2. Special purpose chassis is specially developed for rural market, even narrow country road can be easily handled.

3. Steel structure adopts high-strength steel shot blasting, structure strength improved 20%, strong bearing capacity and great anti-knock effects.

4. Concrete mixer tank with Superior performance

Optimized design of concrete mixing tank, improve loading ability, mixing on average without separation.

Mixing blade adopt three-dimensional double helix mixing design, reducing remnant rate to 0.6%, better than international standard 2%, leading the industry standard 0.7%-1%.

The blade has unique wear-resisting protection structure, improving blade service life 80%.

5. The design of low angle of inclination, center of gravity is lower 5% than similar concrete mixing truck, safety factor higher 10%.

6. Simple operation and useful application

Feeding inlet and discharging outlet with reasonable design, faster feeding and discharging, easy operation.

Mixing Blade

Mixing Drum

Mixer drum workshop

Qingdao JIUHE Heavy Industry Machinery Co., Ltd. | JIUHE CMS

Mixer truck assamble workshop

JIUHE small mixer turck working in Philippines

Factory over view

Our company Team

Features

Capacity	6m3
Chassic brand	Dongfeng
Wheelbase（mm）	3600
number of axles	2
track front（mm）	1810
track rear（mm）	1800
front overhang（mm）	1250
rear overhang （mm）	1850
approach angle/departure angle	25/23
Tyre Number	6
Tyre Size	10.00-20
Plate Spring Number	8 10
Fuel	Diesel
Engine emission standard	National IV
Engine brand	YUCHAI
Power	134kw/180HP
Engine rated speed（r/min）	2800
Engine idling speed（r/min）	700~750
clutch	biplate Dried constant joint
type of belt drive	shaft drive transission
drive mode	Rear Wheel Drive
Turning form	Hydraulic power steering
Service brake	Air-brake
Parking braking	Air brake braking
Max. speed	85
Concrete mixing truck Demission（mm）	7220x2490*3630
Mixing volume（m³）	6
Geometric volume（m³）	9.3
mixer drum max. dia.（mm）	Ø2100
angle of inclination（°）	16
feeding rate（m³/min）	≥2
Discharging rate（m³/min）	≥1.5
drum rotation speed（r/min）	3~9
discharging remnant rate	≤0.1%
water supply mode	air pressure supply
water tank volume（L）	150
radiator	24v air-cooled
reduction box	Shijiazhuang Keyi
motor	Zhenjiang Dali
hydraulic pump	Ruian Shengjie
