Description

Brief Introduction

JIUHE concrete mixing plant is integrated unit for centralized mixing concrete, with superior mechanized automatic degree, higher productivity, ensure concrete quality and save cement. Following the development in new rural construction and higher construction requirement, JIUHE adopt centralized mixing to get better environmental protection, having Absolute advantages on construction technology, working period, cost and quality, with completely vast market prospect.

HZS series concrete mixing plant is according to GB10172-88 《concrete mixing plant technical conditions》, which is designed and manufactured with advanced technology that introduced and absorbed from similar products in German, the function is taking raw materials of concrete such as cement, water, sand, stone, powder, additives and so on, using specific mix proportion that made in advance, producing the finished concrete with excellent quality. Concrete mixing plant is widely applied in various constructions such as rural, highway, railway, bridge and so on.

Main Technical Feature

1.German technology concrete mixer,energy saving, high efficiency, better concrete quality.

2.German technology dual floating oil seal ring design, longer service life of shaft-end seal

3.Control software, stronger function, the operation management for full set of concrete machine is available.

4.Aggregate inching supplying technology and automatic scale deducting function can get higher precision for dynamic measurement.

5.Higher dynamic measurement precision with function of powder fast or slow feeding

6.Total computer automatic control, cooperating with high-quality weighing instrument, high control precision on batching.

7.German Siemens electric parts, Taiwan EVOC, advanced manufacturing technique, stable and reliable performance.

8.Modular design, simple and convenient installation and testing.

9.The maintenance access of concrete mixer is equipped with power-off protection upon opening the door, safe and reliable operation.

10.Special seal structure, good airtightness, little dust and great working condition.

Details:

Construction Drawing:

Qingdao JIUHE Heavy Industry Machinery Co., Ltd. | JIUHE CMS

Mixing Station:

Factory over showing

Group administrators Team

Features

Model	HZS50	HZS60	HZS75
Theoretical Productivity (m3/h)	50	60	75
Mixer Model	JS1000	JS1000	JS1500
Mixing motor Power(kw)	37	37	55
Feeding capacity(L)	1500	1500	2250
Output capacity(L)	1000	1000	1500
Batching plant model	1600	1600	2400
Number of Aggregate storage bin	3	3	3
Feeding mode	Hoist skip	belt conveyor	Hoist skip
Hoister power	15	-	22
Cycling Period(s)	72s	60	72s
Max. aggregate size(mm)	Φ60	Φ60	Φ80
Discharging height(m)	3.5-3.9	4.0	3.5-3.9
Aggregate weighing Precision	±2%	±2%	±2%
Cement weighing precision	±1%	±1%	±1%
Fly ash weighing precision	±1%	±1%	±1%
Water weighing precision	±1%	±1%	±1%
Additive weighing precision	±1%	±1%	±1%
